Zusätzliche Information
| Größe | L |
|---|---|
| Rahmen | ONE-FORTY LITE III, 143mm suspension travel 29", Material: Aluminium, 29×2.5" max. wheelsize, 148x12mm axle standard, BSA bottom bracket standard |
| Gabel | Marzocchi Z1, Air, 150mm suspension travel, Tapered, 44mm fork offset, 29×2.6" max. wheelsize |
| Dämpfer | RockShox Deluxe Select+, lockout |
| Schaltwerk | Shimano SLX M7100 Shadow+ |
| Schalthebel | Shimano SL -MT500-IL/Shimano XT, Multi Release |
| Kurbel | Race Face Aeffect, 32 teeth, 170 mm-S, 175 mm-M up |
| Kassette | Shimano Deore M6100, 10-51 teeth, 12 speed |
| Bremsen | Shimano SLX M7120, 4 Piston, 203/203mm |
| Lenker | MERIDA TEAM TR, Material: Aluminium, 780mm width, XS/S 18mm rise, M/L/XL 30mm rise |
| Griffe | Merida Expert EC |
| Vorbau | MERIDA EXPERT eTRII, Material: Aluminium, 35mm diameter, 0° stem angle, 50 mm |
| Steuersatz | Merida 8158 |
| Sattel | MERIDA EXPERT SL, V-mount, incl. MERIDA minitool |
| Sattelstütze | MERIDA TEAM TR, 34.9mm diameter, 10mm setback, 30-230mm travel seatpost |
| Sattelklemme | Merida Expert |
| Felgen | MERIDA EXPERT TR, 29mm inner width, Material: Aluminium, Tubeless ready |
| Reifen | Maxxis Minion DHF/Maxxis Dissector, 29×2.5", fold, TR EXO 3C MaxxTera, 29×2.4", fold, TR EXO+ MaxxTerra |
| Zulässiges Gesamtgewicht | 135 kg |
