Zusätzliche Informationen
| Größe | L, XL, XXL |
|---|---|
| Rahmen | eONE-FORTY LITE III, Material: Aluminium, 133mm suspension travel, 27.5×2.8" max. wheelsize, 148x12mm axle standard, intube |
| Gabel | Marzocchi Z2 eMTB+, Air, 140mm suspension travel, Tapered, 51mm fork offset |
| Dämpfer | SR Suntour EDGE, lockout |
| Motor | Shimano EP8, 85Nm |
| Batterie | Simplo Internal Battery, 750Wh |
| Display | Shimano SC-E5003A |
| Schaltwerk | Shimano Deore RDM5100 11 |
| Schalthebel | Shimano SL -MT500-IL/Shimano Deore M5100 |
| Kurbel | Shimano FCEM600, 165 mm |
| Kassette | Shimano M5100, 11-51 teeth, 11 speed |
| Kettenblatt | Shimano CRE70-B, 34 teeth |
| Schalthebelklemme | Jagwire Flex-SL:CP |
| Bremsen | Shimano M4100, 4 piston |
| Bremsscheiben | Shimano RT30/Shimano RTEM300, 203 mm |
| Lenker | MERIDA EXPERT eTR, 780mm width, 20mm rise |
| Griffe | MERIDA EXPERT EC |
| Vorbau | MERIDA EXPERT eTRII, Material: Aluminium, 35mm diameter, 0° stem angle, GoPro & Supernova mount, 50 mm |
| Steuersatz | MERIDA 8152 |
| Sattel | MERIDA COMP SL, V-mount |
| Sattelstütze | MERIDA COMP TR, 30.9mm diameter, 0mm setback, S/M 100mm travel seatpost – L/XL 125mm travel seatpost – XXL 150mm travel seatpost |
| Sattelklemme | MERIDA EXPERT |
| Scheinwerfer | Lezyne E-Bike Power E115, StVZO, reverse MERIDA Custom Mount |
| Rücklicht | Dlight CG-214RG, STVZO, USB |
| Schutzbleche | C093-02F + C093-02R |
| Naben | Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Achsen | MERIDA EXPERT TR, including removeable lever, 6/4mm allen key |
| Felgen | MERIDA COMP TR, 29mm inner width, Material: Aluminium, Tubeless ready |
| Reifen | Maxxis Rekon, 29×2.4", wire, DUAL, 27.5×2.6", wire, EXO |
| Zulässiges Gesamtgewicht | 140 kg |
